Newlands FM430 Barracuda

The new FM430 Barracuda is Newland’s most aggressive and efficient fixed mount scanner to date, making it a strong all-round solution. It’s equipped with a megapixel camera that scans virtually any 1D and 2D barcode with impressive speed and ease.

Performance

• Image Sensor: CMOS 1280 * 800
• Processor: 1GHz,X1500
• Illumination: White LED
• Aiming Laser diode or green LED
• Depth of Field: EAN 13 (13mil) 55-360mm
• Depth of Field: Code 39 (5mil) 70-180mm
• Depth of Field: PDF417 (6.67mil) 55-160mm
• Depth of Field: Data Matrix (10mil) 50-170mm
• Depth of Field: QR (15mil) 40-210mm
• Minimal Print Contrast: 25%
• Scan Angle Roll: 360°
• Scan Angle Pitch: ±55°
• Scan Angle Skew: ±55°
• Field of View Horizontal: 51°
• Field of View Vertical: 32°
• Scan Modes: Sense mode, Continuous mode, Level mode, Pulse mode
• Scan Rate: 60 frames per second

Data Capture

• 1D: All major 1D symbologies, including EAN-13, EAN-8, UPC-A, UPC-E, Code 128, Code 39, Codabar,UCC/EAN 128, RSS, ITF, ITF-14, ITF6, Standard 25, Matrix 25,COOP 25, Industrial 25, Plessey, MSI Plessey, Code 11, Code93, Code 49, Code 16K.
• 2D: All major 2D symbologies, including PDF417, QR Code, Data Matrix, AZTEC, CSC, Maxicode,Micro QR, Micro PDF417, GM , Code One.

Physical

• Dimensions (mm): 41.5(W)×49.5(D)×24.3(H)mm
• Weight: 75g
• Material: PC,ABS
• Interfaces: RS-232, USB
• Notifications: Beep, LED indicator
• Input Voltage: 5VDC±5%
• Current: @ 5VDC Operating 276.8mA (typical), 322.7mA (max.)
• Current: @ 5VDC Standby 83.3mA
• Power Supply Input: DC5V, 1.5A
• Power Supply Output: AC100~240V, 50~60Hz

Environmental

• Operating Temperature: -20℃ to 60℃ (-4°F to 140°F)
• Storage Temperature: -40℃ to 70℃ (-40°F to 158°F)
• Humidity: 5%~95% (non-condensing)
• Electro Static Discharge (ESD): ±14 kV (air discharge), ±8 kV (direct discharge)
• Drop: 1.5m
• IP Rating: IP54

Accessories

• Standard: USB Cable
• Optional: RS232 Cable, Adapter

Software

• Configuration Tools: EasySet

Certifications

• Hardware: FCC Part15 Class B, CE EMC Class B, RoHS, IEC60825, IEC62471, KC

Warranty

• Standard: 2 years
