Newland HR12 Anchoa Handheld Barcode Reader

Newland HR12 Anchoa Handheld Barcode Reader

The HR12 Anchoa handheld scanner is a practical & user friendly entry level scanner at an extremely competitive price. The Anchoa incorporates Newland’s 1D chip technology for excellent 1D barcode scanning performance at exceptionally low power consumption.

Performance

• Image Sensor: CCD 1500
• Processor: 0110 Chip
• Illumination: Red LED (610nm~640nm)
• Depth of Field: EAN 13 (13mil) 50-655mm
• Depth of Field: Code 39 (5mil) 55-165mm
• Minimal Print Contrast: 30%
• Scan Angle Roll: 30°
• Scan Angle Pitch: ±60°
• Scan Angle Skew: ±60°
• Field of View Horizontal: 40°
• Scan Modes: Trigger Mode, Sense Mode, Continuous Mode, Command Trigger Mode
• Scan Rate: 300 scans per second

Data Capture

• 1D All major 1D symbologies, including EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code 128, Code 93, ITF-6,ITF-14, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5,GS1 Databar, Code 39, Code 11, MSI-Plessey, Plessey.

Physical

• Dimensions (mm): 163.0×68.4×58.5mm
• Weight: 130g (including USB cable)
• Material: PC, ABS
• Buttons: Trigger
• Interfaces: USB
• Notifications: Beep, LED indicator
• Input Voltage: 5VDC±5%
• Current @ 5VDC Operating: 55±5mA
• Current @ 5VDC Standby: 21mA±2mA

Environmental

• Operating Temperature: -20℃ to 60℃ (-4°F to 140°F)
• Storage Temperature: -40℃ to 85℃ (-40°F to 185°F)
• Humidity: 5%~95% (non-condensing)
• Electro Static Discharge (ESD): ±8 KV (contact discharge); ±10 KV (air discharge)
• IP Rating: IP41

Certifications

• Hardware FCC Part15 Class B, CE EMC Class B, RoHS

Warranty

• Standard 5 years
