Image display

• Active display area, horizontal dimension: 697,685 mm
• Active display area, vertical dimension: 392,256 mm
• Screen size (rounded to nearest integer): 80 cm
• Screen size (rounded to nearest integer): 32 inch
• Display technology: LCD / LED lit
• Backlight source: LED Matrix
• Resolution (Horiz x Vert): 1366 x 768 pixel
• Colour depth: 8bit
• Image refresh frequency: 60 Hz
• Smooth motion rate: 120
• Maximum brightness of white: 300 cd/m2
• Native contrast ratio: 3000 : 1
• Viewing Angle (Horiz / Vert): 178 / 178 Degrees
• Response Time: 6,5 ms

Connectivity

• RF – Radio frequency input: 1
• AV input: 1
• USB interface type 2.0 (Qty / List ….): 2 / USB 1, USB 2
• Optical digital audio output (SPDIF): 1
• Earphone jack: 1

HDMI ports

• HDMI inputs: 2
• HDMI type 1.4 with HDCP version 1.4: HDMI 1, HDMI 2
• ARC – Audio Return Channel: HDMI 1
• CEC – Consumer Electronics Control via HDMI: Yes

Digital TV reception

• Television system (DVB-T / DVB-T2+S2): Yes / Yes
• Video decoder (MPEG2 / MPEG 4): Yes / Yes
• AC3 Surround sound decoder: Yes
• Subtitles: Yes

Analogue TV reception

• Colour-Sound systems in VHF band: PAL B
• Colour-Sound systems in UHF band: PAL B
• Stereo sound decoder {A2, Nicam, ….}: NICAM
• Subtitles: Yes

Image processing

• Zoom function settings (4:3 / 16:9 / Auto / Zoom 1 / Zoom 2): Yes / Yes / Yes / No / No

Sound

• Audio power output per channel: 6 Watt
• Number of speakers (Tweeter / Midrange / Woofer): 0 / 1 / 0
• Automatic volume level (AVL): Yes
• Audio equalizer: Yes
• Dolby Digital: Yes
• Features: On / off timer: Yes
• Power off if no signal: Yes
• Sleep timer: Yes
• Program lock: Yes
• User interface: Linux
• Software version OSD indication: Yes
• Legal requirements: Disclaimer / Acceptance of Terms: Yes / Yes
• Favourite channels list: Yes

USB media player

• Personal Video Recorder: Yes
• Time Shift: Yes
• DTV Recording (EPG scheduling / start from Standby): Yes / Yes
• DMP – Digital media player content (Music / Video / Photos / Text): Yes / Yes / Yes / No
• DMP File allocation table (FAT / FAT32 / exFAT / NTFS): Yes / Yes / No / Yes
• PVR File allocation table (FAT / FAT32 / exFAT / NTFS): Yes / Yes / No / Yes

Hotel lock

• Protected Hotel lock submenu (Password / fixed code): No / Yes
• Sub-menu lock, including tuning lock: Yes
• Power on RF channel selection: Yes
• Power on mode (On / Standby / Last): Yes / Yes / Yes
• Inputs access (Enable / Disable): Yes
• Maximum volume lock: Yes
• Power on volume: Yes
• Power on, apply default sound / image settings: Yes
• Power on source selection: Yes

Hardware

• Processor / Cores: MSD3666
• Colour (Front bezel, rear, stand): Black / Black / Black
• Standby consumption: < 0.5W
• Compact packaging: Yes
• Supply range [Voltage / Frequency ]: 100 ~ 240V / 50, 60Hz

Installation

• Power cord length: 155 cm
• Stand area (Width / Depth): 671 x 160 mm
• Wall mount dimensions (Horiz x Vert): 100 x 200 mm
• Wall mount, screw thread: M6
• VESA compliance: Yes

Accessories

• Remote controller (Technology / Part number ): IR / EN2T30H
• Battery (size / quantity): AAA / 2
• User manual (Available online) / Quick setup guide (Print): 1 / 1
• Warranty [In User manual | In separate sheet]: In separate sheet

Dimensions

• Dimensions with stand (W x H x D): 717 x 469 x 160 mm
• Dimensions without stand (W x H x D): 717 x 427 x 86 mm
• Carton box dimensions (W x H x D): 811 x 129 x 515 mm
• Net weight (with stand / without stand): 3.6 / 3.7 kg
• Gross weight: 5,5 kg
• EMC – Electromagnetic Compatibility: Yes
• CB – Electrical safety: Yes
• HDMI: Yes
• Dolby Digital: Yes
